| Certification: | CE ISO |
| Model Number: | KQ-1500L |
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Wooden Box |
| Delivery Time: | 10 days after get your advance payment |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 100 Set Per Month |
| Name: | Ice Cream Production Line Aging Tank | Material: | Sanitary Stainless Steel 316 |
|---|---|---|---|
| Turnkey Project: | Yes | Flow: | 500L/Hour - 15000L / Hour |
| Trade Mark: | Kaiquan | Warranty: | One Year After Operating |
| Packing: | Wooden Box | Spare Part: | Supply |
| Highlight: | ice cream processing machine,ice cream mixing tank |
||
Semi Automatic Business Ice Cream Production Line Aging Tank Maturation Tank
1. Introduction :
Structure characteristics:
1. Adopt structure of internal tank and external package, with heat preservation materials inside.
2. Material are all sanitary stainless steel.
3. Humanized structure design and easy to operate.
4. Transition area of interior wall on tank adopts arc for transition to ensure no dead comer of sanitation.
Configuration of tank:
1. Quick open manhole.
2. Various types of CIP cleaners.
3. Fly and insect resistant sanitary breathing cover.
4. Adjustable triangular bracket.
5. Dismountable materials input pipe assembly.
6. Thermometer (According to customer requirements ).
7. Ladder (According to customer requirements ).
8. Liquid level meter and level controller (According to customer requirements ).
9. Eddy-proof board
2. Technical Parameter :
| Volume | 300L | 400L | 500L | 600L | 800L | 1000L | 1500L | 2000L | 3000L |
| Body diameter(mm) | 800 | 800 | 900 | 1000 | 1000 | 1000 | 1200 | 1300 | 1600 |
| Body height(mm) | 600 | 800 | 800 | 800 | 1000 | 1220 | 1220 | 1500 | 1500 |
| Motor power(kw) | 0.55 | 0.55 | 0.55 | 0.55 | 0.55 | 0.75 | 1.5 | 2.2 | 3 |
| Stirring speed(rpm) | 36RPM | ||||||||
| Working pressure | ≤ 0.1Mpa | ||||||||
| Working temperature | < 180° C | ||||||||
| Accessories | Thermometer, safety valve, pressure gauge | ||||||||
